- LiFePO4 Chemistry
- Peak Discharge of 1,000A @ 5s, 800A @ 10s
- Max Charge Current of 300A (Continuous)
- Max Discharge Current of 300A (Continuous)
- Victron Comms - CANBUS entire string of batteries to Victron Ecosystem
- HEATED - Internal heating allows for charging in sub-zero conditions
- BLUETOOTH - iOS and Android Apps
- BLUETOOTH - Over the air Firmware update via the app
- External Battery Gauge - Touch Screen (Optional - Coming soon)
- Communications Box for more Inverter, NMEA2k compatibility (Optional - Coming soon)
- IP67 Rated, Dust and WATERPROOF
- Over current and short circuit protection
- High & low temperature disconnects
- Max (4) in Series up to 48V
- Max (16) in Parallel
- 6000+ Cycle life & Maintenance-free
- 11 Year Manufacturer Warranty
Configuration
Weights & Dimensions
Recommended Charge Settings
To properly charge your Epoch Batteries, you will want to verify that any charging component in your system is capable of being programmed for the following specifications. Charging components can include, but are not limited to converters, inverter chargers, solar charge controllers, DC to DC chargers, etc.
- Bulk/Absorption: 14.2V – 14.6V
- Absorption Time: Two batteries in parallel connections require 30 minutes 200Ah
- Float: 13.4V – 13.8V
- Equalization: 14.4V/ Disabled
- Temperature Compensation: 0/Disabled
- Charge Rate: 50% of the battery or battery bank capacity
- Battery Charge Temperature Range: 32°F (0°C) to 131°F (55°C)
- Battery Discharge Temperature Range: -4°F (-20°C) to 140°F (60°C)
- Cell Charge Temperature: 32°F (0°C) to 131°F (55°C)
NOTE: Not all chargers are capable of multistage charging. If yours is not, you will want to verify it can be programmed for the Bulk/Absorption voltage and have the other items mentioned disabled if applicable. Consult your charger's manual or the manufacturer.
Tournament Package
We also have a Tournament package with the 105ah batteries and 15 amp charger
Battery Specialist
Drewcraft Marine has a full selection of Lithium Batteries compatible with old and new boats
Lithium Chargers
We have a full line of Lithium compatible chargers for all the major manufactures
Epoch Compatibility
Compatible with the following chargers: Epoch, Noco Gen Pro, Dual Pro PS/ Auto, Minnkota Precision, Pro Mariner/Pro Tournament Elite, Stealth, Troll Bridge DC, Power Pole
Magnuson-Moss Warranty Act: A vehicle manufacturer cannot legally void the warranty on a vehicle due to an aftermarket part unless they can prove that the aftermarket part caused or contributed to the failure in the vehicle (per the Magnuson Moss Warranty Act (15 U.S.C. 2302(C)). Epoch Batteries have proprietary software embedded in the Battery Management Systems that make them 100% compatible with Mercury 250 hp motors and other leading brands.
Stealth I Charge on the Go
Drewcraft stocks a full line of Stealth I Charge on the Go Chargers
More Chargers
Frequently Asked Questions
if your charger puts out 14.4 to 14.6v at constant current and has a manual setting for AGM like the Minnkota 440pc and 460pc you can use it for lithium
All outboards with an alternator and most any outboard 2001 and newer are fine to use a lithium starter battery.
